MaxiSys MS906BT

MaxiSys MS906BT is the latest addition to the MaxiSys product line of advanced wireless diagnostic devices. The device is based on the Android operating system featured with the best possible coverage of OE-level diagnostics and ECU coding capability. Utilizing the powerful Exynos 5260 6-core processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), an 8” capacitive HD touch screen, and long-distance wireless communication, the MaxiSys MS906BT efficiently provides comprehensive vehicle diagnostics and analysis.

  • Extraordinarily powerful Samsung Exynos Hexa-core processor
  • 8.0” 1024×768 LED-backlit glossy Multi-Touch capacitive display with IPS technology for ultra-mobility
  • Internal reliable 32GB SSD for better performance
  • Built-in 8-megapixel rear camera with autofocus and flashlight
  • 802.11b/g/n Wi-Fi to access your favorite web resources
  • Unique ergonomic design with rubberized outer protection and a rugged internal housing
  • Built-in rechargeable lithium-polymer battery for up to 14 hours of continuous operation
  • USB, audio and auxiliary ports make it easy to connect accessories
  • Open source Android Operating System for fast boot-up and multitasking
  • Easy and intuitive navigation makes finding what you need simple and fast
  • The most extensive complete system coverage for more than 80 US, Asian and European makes and models
  • Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding
  • Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.
  • Smart AutoVIN technology for identifying vehicle easily
  • Automatic system and software updates with real-time push message notifications via internet
  • Instant remote control tech support anytime, anywhere
  • Cloud-based MaxiFix online community provides a vast database of diagnostic and repair tips and proven filed fixes
  • Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors
  • One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
  • Enhanced wireless BT connectivity between the display tablet and VCI device allows greater mobility and ease at work
  • Convenient data management system for managing internal program applications and reviewing data
Operating SystemAndroid™ 4.4.2, KitKat
ProcessorSamsung Exynos T5260 6-Core Processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15)
Memory2 GB RAM & 32 GB ROM
Display8.0" LED capacitive touch screen with 1024x768P resolution
ConnectivityWi-Fi (802.11 b/g/n), USB: 2.0, Mini USB 2.0, Wireless BT V2.1+EDR, Class1, HDMI 1.4a, SD Card (support up to 32 GB)
Camera (rear)Rear-facing, 8.0 Megapixel, AF with Flashlight
SensorsGravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/OutputMicrophone, Single Speaker, 3-Band 3.5 mm stereo/standard headset jack
Power and Battery10,000 mAh 3.7 V lithium-polymer battery, Charging via 12 V AC/DC power supply
Input Voltage12 V (9-35 V)
Power Consumption5 W
Operating Temperature -10 to 55°C (14 to 131°F)
Storage Temperature-20 to 70°C (-4 to 158°F)
Dimensions (W x H x D)270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)
WeightNW: 0.93 kg (2.05 lb.)
NW: 1.05 kg (2.3lb.)
  • AC/DC Adapter (12V)
  • Adapter for Chrysler-16 (America Only)
  • Carrying Case
  • Quick Reference Guide
  • Adapter for GM/Daewoo-12
  • Adapter for Benz-38
  • Adapter for Mitsubishi/Hyundai-12+16
  • Adapter for Honda-3
  • Adapter for VW/AUDI-2+2
  • Packing List
  • Adapter for Benz-14 (Europe Only)
  • User Manual
  • MaxiVCI V100
  • Lighter Fuse
  • Adapter for BMW-20
  • Adapter for Kia-20
  • Adapter for Nissan-14
  • Cigarette Lighter
  • Soft Cloth
  • Mini USB Cable
 MaxiSys
Elite
MaxiSys
MS906
MaxiSys
MS906BT
MaxiSys
MS906TS
MaxiSys
MS908CV
MaxiSys
MS908S
MaxiSys
MS908S Pro
Function
All Systems DTC Scan
Service Function
Bi-Directional Control
Auto VIN Technology
ECU Coding----
ECU Programming----------
MaxiFix Cloud-Based Info System
Data Manager
Shop Manager
Remote Support
Pre-scan Report
& Post-scan Report
US OnlyUS OnlyUS Only--US OnlyUS Only
Print Feature
Multi-language Support
Coverage
American/Asian/European Coverage (1996-Present)
Hardware
Display Size9.7"8"8"8"9.7"9.7"9.7"
Wireless VCIMaxiFlash Elite--MaxiVCI V100MaxiVCI V100MaxiFlash EliteWireless Diagnostic InterfaceMaxiFlash Elite
Battery Life15400 mAh
3.7 V
5000 mAh
3.7 V
10000 mAh
3.7 V
10000 mAh
3.7 V
11000 mAh
3.7 V
11000 mAh
3.7 V
11000 mAh
3.7 V
Memory Storage64GB32GB32GB32GB64GB64GB64GB
Connector Kit
Options
TPMS------------
Oscilloscope--
Inspection Camera--
ADAS----
