| Recommended Use |
Indoor |
| Operating System |
Android™ 4.4.2, KitKat |
| Processor |
Cortex-A9 processor (1.5 GHz) |
| Memory |
32GB |
| Display |
7-inch LCD capacitive touch screen with 1024×600 resolution |
| Connectivity |
Mini USB 2.0 • USB 2.0 • Wi-Fi • HDMI Type A • Micro SD card (supports up to 32GB) |
| Sensors |
Light sensor for brightness auto changing |
| Audio Input/Output |
Input: N/A
Output: buzzer |
| Power and Battery |
3.7 V/5000 mAh lithium-polymer battery • Charges via 5 VDC power supply |
| Tested Battery Life |
Around 7 hours of continuous use |
| Battery Charging Input |
5 V/1.5 A |
| Power Consumption |
600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
| Operating Temp. |
-10 to 60°C(14 to 140°F) |
| Storage Temp. |
-20 to 70°C (-4 to 158°F) |
| Operating Humidity |
5% – 95% non-condensing |
| Dimensions (W x H x D) |
270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”) |
| Net Weight |
885 g (2.31 lb.) |
| Protocols |
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 |
