| Operating System |
AndroidTM 4.4.2, KitKat |
| Processor |
Samsung Exynos Six-core Processor (1.3GHz Quad-core ARM Cortex-A7 + 1.7GHz Dual-core ARM Cortex-A15) |
| Memory |
2GB RAM & 64GB On-board Memory |
| Display |
9.7 inch LED capacitive touch screen with 1024×768 resolution |
| Connectivity |
Wi-Fi (802.11 a/b/g/n/ac)
USB: 2.0
BT v.2.1 + EDR
SD Card (Support up to 32GB)
HDMI |
| Camera |
8.0 Megapixel, AF with Flashlight |
| Sensors |
Gravity Accelerometer, Ambient Light Sensor (ALS) |
| Audio Input/Output |
Microphone
Dual Speakers
3-Band 3.5 mm stereo/standard headset jack stereo/standard headset jack |
| Power and Battery |
11000 mAh 3.7 V lithium-polymer battery
Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C |
| Input Voltage |
12 V (9-24 V) |
| Power Consumption |
6.5 W |
| Operating Temp. |
0 to 50°C (32 to 122°F) |
| Storage Temp. |
-20 to 60°C (-4 to 140°F) |
| Dimensions (W x H x D) |
300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”) |
| Weight |
NW: 1.42 kg (3.13 lb.) GW: 8.052 kg (17.75 lb.) |
| Protocols |
ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW,
SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN,
GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939,
SAE J1708, Fault-Tolerant CAN |
